Multi Spot Welding Machine Cascade
Product Details:
X
Product Description
Machine Category:
-Multi Spot Welding Machine
Make:
- WELDTRONIC
Model :
-WIPL - MSSCMC2005
Key Features :
Instant Welding
- Available With Fixture
- Aesthetic Welding Quality
- Easy Sliding Of Job
- Individual Spring Pressure Adjustable
- Micro Processor Based Control
- Easy Operation
- Strong And Sturdy Body
- 10 Storable Programs For 10 Jobs
- Easy Pitch Adjustment
- Electrodes Adjustable in X & Y axis
- Micro Processor Based Control
Specifications :
| Mesh Width/Throat | 1200mm. |
| Welding range (wire dia in mm.) | 2.5to 4mm |
| Line wire pitch(mm) | 50-150mm. |
| Welding Pressure/Electrode | 100 -kgf |
| Short Circuit Current In KA Throat 350 mm | 25l/min. |
| Free Air consumption for 100 Operation with 25 mm. Maximum Working Stroke Ltr. | 200 |
| Supply Cable Size copper/Al. mm. sq. | 35 mm. sq. Cu. |
| Main Supply Switch fuse rating in Amps | 100 |
| H.R.C Fuse rating in Amps | 96 |
| Max of no. strokes/min | 30 |
| No. of Trx. | 1/2 |
| No. of Electrodes | 6 - 12 |
| Trx. Workable KVA @ 50% duty | 100 |
| Short circuit KVA | 100 |
