Dual Head Spot Welding Machine
Product Details:
X
Product Description
Make: - WELDTRONIC-POWERJET
Model: - WIPL - DSPWMC-100
Key Features :
- Instant Welding
- Available With Fixture
- Clean Welding Appearance
- Easy Sliding Of Job
- No Fumes While Welding
- Micro Processor Based Control
- No Skilled Labour Required
- Strong And Sturdy Body
- 10 Storable Programs for 10 Jobs
- Easy Pitch Adjustment
- Electrodes Adjustable in X & Y axis
- Micro Processor Based Control
- Strong & Rigid Body
Specifications :
| Throat | 300 mm |
| Welding range(sheet thick in mm.) | 1.0 to 1.2 mm / 3 - 6 mm. wire |
| Line wire pitch(mm) | 50-200 mm. |
| Welding Pressure/Electrode | 100 -kgf |
| Short Circuit Current In KA Throat 350 mm | 25 |
| Rate of Water Flow | 15 l/min. |
| Free Air consumption for 100 Operation with 25 mm. Maximum Working Stroke Ltr. | 200 |
| Supply Cable Size copper/Al. mm. sq. | 25 mm. sq. Cu. |
| Main Supply Switch fuse rating in Amps | 100 |
| H.R.C Fuse rating in Amps | 96 |
| Max of no. strokes/min | 30 |
| No. of Trx. | 1 |
| No. Electrodes | 2 |
| Trx. Workable KVA @ 50% duty | 100 |
| Short circuit KVA | 100 |
